Fiche technique
TP-Link : 24-PORT GIGABIT L2 SWITCH MANAGED avec 4 GIGABIT SFP SLOTS
TP-Link
TP-Link JetStream TL-SG3428 - Commutateur - Géré - 24 x 10/100/1000 + 4 x Gigabit SFP - Montable sur rack
PRINCIPALES CARACTÉRISTIQUES
Description du produit
TP-Link JetStream TL-SG3428 - commutateur - 28 ports - Géré - Montable sur rack
Type de périphérique
Commutateur - 28 ports - Géré
Type de boîtier
Montable sur rack
Sous-type
Gigabit Ethernet
Ports
24 x 10/100/1000 + 4 x Gigabit SFP
Performances
Capacité de commutation: 56 Gbps,Taux de transfert des paquets: 41,66 Mpps
Capacité
Files d'attente prioritaires: 8,Nombre maximum de groupes d'agrégation: 8,Ports per aggregation group: 8,Groupes VLAN: 4000,Entrées ARP: 316
Taille de la table d'adresses MAC
8 000 entrées
Support de cadre Jumbo
9KB
Protocole de Routage
IGMPv2, IGMP, IGMPv3, MLDv2, MLD
Protocole de gestion à distance
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, ICMP
Caractéristiques
Contrôle du flux, prise en charge du réseau local (LAN) virtuel, IGMP snooping, mise en miroir des ports, Prise en charge du protocole STP (Spanning Tree Protocol), prise en charge du protocole MSTP (Multiple Spanning Tree Protocol), DHCP snooping, prise en charge de la liste de contrôle d'accès (ACL), serveur DHCP, snooping MLD, contrôle de la bande passante, sans ventilateur, prise en charge LLDP, relais DHCP, protocole de contrôle de l'agrégation de liens (LACP), Multicast VLAN Registration (MVR), Dynamic VLAN Support (GVRP), Neighbor Discovery Protocol (NDP), prévention des boucles, isolation des ports, Class of Service (CoS), Strict Priority (SP), journal de système, Protection de la source IP, Inspection ARP, Bridge protocol data unit (BPDU), Link Aggregation, support image double, départ rapide, authentification d'adresse MAC, Authentication, Authorization and Accounting (AAA), Static Link Aggregation, Voice VLAN, LLDP-MED, groupe VLAN, proxy ARP, Zero-touch provisioning (ZTP), Denial of Service (DoS) protection, Ethernet économe en énergie (EEE), BPDU Filter, Round Robin pondéré (WRR), Head-of-line (HOL) Blocking Prevention, détection de bouclage, Rapid Reconfiguration of Spanning Tree (RSTP), support de planification des files d'attente, redémarrage planifié, Maximum Likelihood Detection (MLD), prioritisation DSCP, protection BPDU
Normes de conformité
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP)
Alimentation
CA 120/230 V (50/60 Hz)
Dimensions (LxPxH)
44 cm x 18 cm x 4.4 cm
